China manufacturers solar photovoltaic panel multi crystalline silicon solar panel 265w 270w 275w for saleIn well protected carton or wooden box with pallets.
Solar Panel Details:
250W-300W 1640mm*992mm*35mm per piece
30pcs per pallet, 420pcs fill into 20GP, 840pcs fill into 40HQ.
300W-375W 1960mm*992mm*40mm per piece
27pcs per pallet, 324pcs fill into 20GP, 648pcs fill into 40HQ.
|ELECTRICAL DATA @ STC||FGET-270 PD05||FGET-275|
|Peak Power Watts-PMAX (Wp)* Power||270||275||280||285|
|Output Tolerance-PMAX (W)||0/+5||0/+5||0/+5||0/+5|
|Maximum Power Voltage-VMPP (V)||30.9||31.1||31.4||31.6|
|Maximum Power Current-IMPP (A)||8.73||8.84||8.92||9.02|
|Open Circuit Voltage-VOC (V)||37.9||38.1||38.2||38.3|
|Short Circuit Current-ISC (A)||9.22||9.32||9.4||9.49|
|Module Efficiency ηm (%)||16.5||16.8||17.1||17.4|
|STC: Irradiance 1000 W/m², Cell Temperature 25 °C, Air Mass AM1.5|
|* Measuring tolerance: ±3%|
|ELECTRICAL DATA @ NOCT||FGET-270 PD05||FGET-275|
|Maximum Power-PMAX (Wp)||200||204||208||211|
|Maximum Power Voltage-UMPP (V)||28.6||28.8||29||29.2|
|Maximum Power Current-IMPP (A)||7.00||7.09||7.15||7.23|
|Open Circuit Voltage-UOC (V)||35.1||35.3||35.4||35.5|
|Short Circuit Current-ISC (A)||7.44||7.52||7.59||7.66|
|NOCT: Irradiance at 800 W/m², Ambient Temperature 20 °C, Wind Speed 1 m/s.|
Packaging & Shipping:
1.Package: Carton Box for packaging, or Wooden Box advised for Samples to protect in transportations. Package designed by Clients is welcomed.
2.Shipping: DHL, FEDEX, UPS, EMS, AirWay and By Sea.
Samples are Available for Testing and Market Test. OEM is welcomed for us!!!
Quality assurance testing:
Thermal cycling test
Thermal shock test
Thermal/Freezing and high humidity cycling test
Electrical isolation test
Hail impact test
Mechanical, wind and twist loading test
Salt mist test
Light and water-exposure test
Moist carbon dioxide/sulphur dioxide
- OEM Welcomed
- Warranty: 25 Years
- Certifications can be supported
- Sample for testing is supported
- After-Sale Service: 24 Hour-Hot Line for Consultancy and Technical Support
1. Email us about the PI number, serial number, product S/N number, PCB board number most importantly, is the description of failure products on the condition that it is operated correctly, to the best, show us more detailed pictures or video.
2. We will submit your case to our after-sales department.
3. Usually, in 24 hours, we will email you the best solutions.
|Payment Terms||T/T||EXW||30% T/T in advance, paid the balance before shipment|
|CFR(C&F)||30% T/T in advance, paid the balance against copy of B/L|
|L/C||L/C amount above 50,000 USD, we can accept L/C at sight|
|West Union||Amount lower than 5000usd|
|Delivery time||15 working days after receiving payment for one container|
Q1: How to choose the right Panel?
A1: Tell us your demand, then our sales will recommend a suitable panel for you.
Q2: What's the difference between Mono and Poly panel?
A2: Monocrystalline solar panels have the highest efficiency rates since they are made out of the highest-grade silicon. The process used to make polycrystalline silicon is simpler and cost less. The amount of waste silicon is less compared to monocrystalline.
Q3: How about the delivery time?
A3: 7 days for sample; 15 days for bulk order.
Q4: What is the warranty for solar panels?
A4: 25 years warranty on FGET-Solar product.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
