High viscosity vacuum engine oil purifier diesel purification lubricating oil filter

Application:It is applied to recover and purify various high-precision lubrication oil such as hydraulic oil, mechanical oil, coolant oil, gear oil, heat treatment oil and so on. And also can deal with heavy fuel oil. After treatment by this machine, the oil water content will be less than 80ppm, gas content will be less than 0.

Featured Products


Application:

It is applied to recover and purify various high-precision lubrication oil such as hydraulic oil, mechanical oil, coolant oil, gear oil, heat treatment oil and so on. And also can deal with heavy fuel oil. After treatment by this machine, the oil water content will be less than 80ppm, gas content will be less than 0.1%, filtering accuracy will be less than 5μm, cleanliness will be less than NAS grade6 . It can be used repeatedly in the highly precise hydraulic lubricating system.

Features:

1.Duplex 3D stereo-evaporation, removing the liquid water quickly
2.Adopt μg technology to remove tiny water, such as dissolved water
3.Combination of both network filtration and high polymer material absorbing,to remove impurities from oil
4. Strong capability of breaking emulsification
5. Adopt trapezoidal spiral automatic back flushing system,no need to clean filter element manually
6.Reasonable design, low noise pump, deep purification and low consumable cost.


WORKING PRINCIPLE:

When TYA starts working, oil will be sucked into heater by vacuum pressure, then the oil will be heated and flow into primary filter, where the big impurities are separated.

Then, oil flows into vacuum separator, and flows through a special designed device, which makes per unit volume oil to produce a large surface area, lets the oil exposure in low humidity atmosphere, so the gas and water are separated from oil.



The gas and separated water vapour forms as mixed gas, flows through water tank and cooler, condense into liquid and flows into water receiver, the residual gas is exhausted by vacuum pump.

Oil flows through oil pump and into fine filter, where the tiny impurities are separated.

If the oil is very dirty, or is high water content etc., you can purify the oil circularly for several times, by which to remove the water and impurities completely.



Item  ModelTYA-10TYA-20TYA-30TYA-50TYA-100TYA-150TYA-200TYA-300
Unit
Flow rateL/Min10203050100150200300
Vacuum degreeMpa-0.06 ~ - 0.095
Working PressureMpa≤0.4
Temperature DegreeºC0 ~ 100
Power Supply 380V,3phase, 50HZ  (or as required by customer)
Working noiseDB (A)≤75≤75≤75≤78≤78≤78≤80≤82
Heating PowerKW18182430547292115
Total electric PowerKW202027336080103130
Inlet (outlet) Calibermm2525253242425060
Sizecm150*100*150150*105*160150*105*165160*115*170175*125*180190*160*195190x170x200210x170x210
WeightKg450550600750850100012001500
AFTER TREATMENT
Moisture (water content)≤ 80 PPM
Gas Content≤0.1%
DemulsificationNew oil≤15min, running oil≤30mi
Cleanness≤NAS 1638 Grade 6

High Viscosity Vacuum Engine Oil Purifier Diesel Oil Purification Lubricating Oil Filtration Machine
High Viscosity Vacuum Engine Oil Purifier Diesel Oil Purification Lubricating Oil Filtration Machine
High Viscosity Vacuum Engine Oil Purifier Diesel Oil Purification Lubricating Oil Filtration Machine


High Viscosity Vacuum Engine Oil Purifier Diesel Oil Purification Lubricating Oil Filtration Machine



The oil comparison before filtration and after firtration :

High Viscosity Vacuum Engine Oil Purifier Diesel Oil Purification Lubricating Oil Filtration Machine
